Our self-loading concrete mixer truck integrates loading, mixing, transporting, and discharging in one machine, designed to improve efficiency and reduce labor costs. With different models available, the feeding capacity can be selected from 1.2m³ up to 6.5m³, meeting a wide range of construction needs.
Key Features:
Integrated loading and mixing, no need for additional wheel loader or concrete mixer.
High efficiency, saving up to 5 laborers per day.
Strong power system with reliable hydraulic components.
Suitable for diverse terrains with excellent gradeability.
Cost-effective solution for small to medium construction projects.
Main Parameters:
Feeding Capacity: 1.2m³ – 6.5m³ (Optional)
Drive Form: 4×4
Maximum Speed: up to 30 km/h
Gradeability: 30°
Hydraulic System: Imported core components for stable performance
Water Supply System: Automatic water feeding with time relay
